How To Restart CUCM Web Interface


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

How To Restart CUCM  Web Interface

To do this you need to restart the Cisco Tomcat service, but first what is Tomcat service:

Apache Tomcat (or simply Tomcat) is an open source web server and servlet container developed by the Apache Software Foundation (ASF). Tomcat implements the Java Servlet and the JavaServer Pages (JSP) specifications from Sun Microsystems, and provides a "pure Java" HTTP web server environment for Java code to run.

To display services running on the CUCM:
admin: utils service list

To restart the Tomcat service or simply start it if it is stopped:
admin: utils service restart Cisco Tomcat



وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

How To Add Cisco IP Communicator in CUCM


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

How To Add Cisco IP Communicator in CUCM



وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الخميس، 18 أبريل، 2013

What Is The Difference Between TFTP Option 150 and TFTP Option 66?


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

What Is The Difference Between TFTP Option 150 and TFTP Option 66?

- DHCP Option 150 is Cisco proprietary. The IEEE standard that matches with this requirement is Option 66. Like option 150, option 66 is used to specify the Name of the TFTP server.

- Option 66 is an open standard juniper supports it. RFC 2132 defines option 66.

- DHCP option 150 supports a list of TFTP servers (Multiple Server IPs).

- DHCP option 66 only supports the IP address or the hostname of a single TFTP server.

For some third-party SIP phones, it may be necessary to specify Option 66 (the TFTP server DNS name).



وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الاثنين، 15 أبريل، 2013

How To Manage Access To Cisco Devices Based On Active Directory Authentication


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

How To Manage Access To Cisco Devices Based On Active Directory Authentication

If you have many levels of administrators in your network and you want to give them different privileges, doing so using the local database on Cisco devices is not the optimal, you can grant them access based on the authentication against active directory database where the user will login to the device using his normal user name and password then he will be granted the privilege level that you assigned to his or her group.Note that this lab is done using GNS3 and Windows server 2008 R2.



The commands used on Cisco router:

aaa new-model
!
aaa group server radius IAS
 server 192.168.1.50 auth-port 1812 acct-port 1813
!
aaa authentication login userAuthentication local group IAS
aaa authorization exec userAuthorization local group IAS if-authenticated
aaa authorization network userAuthorization local group IAS
aaa accounting exec default start-stop group IAS
aaa accounting system default start-stop group IAS
!
aaa session-id common
radius-server host 192.168.1.50 auth-port 1645 acct-port 1646 key cisco
radius-server host 192.168.1.50 auth-port 1812 acct-port 1813 key cisco
!
privilege exec level 1 show config
privilege exec level 1 show ip interface brief
!
ip radius source-interface fa0/0
!
line vty 0 4
 authorization exec userAuthorization
 login authentication userAuthentication
 transport input ssh telnet
!
line vty 5 15
 authorization exec userAuthorization
 login authentication userAuthentication
 transport input ssh telnet

وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الأربعاء، 10 أبريل، 2013

Cisco CUCM Log on failed Invalid User ID or Password


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

Cisco CUCM Log on failed Invalid User ID or Password

 On reason for this error when your password contains space, so you need to reset the password from the CUCM console using the following command:


وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الخميس، 4 أبريل، 2013

HP Network Simulator: 11- Web Interface


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 11- Web Interface




وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

HP Network Simulator: 10- Connecting GNS3 and Simware


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 10- Connecting GNS3 and Simware




وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

HP Network Simulator: 9- Simware To Real Network (TFTP Server)


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 9- Simware To Real Network (TFTP Server)



وصلي الله  وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الثلاثاء، 2 أبريل، 2013

Local directory does not appear on Cisco ip phone (or CIPC)

بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

Local directory does not appear on Cisco ip phone (or CIPC)

To slove this issue, entre the following:
ip http server
telephony-service
    url directories http://192.168.20.1/localdirectory
    service local-directory
    create cnf-files

** 192.168.20.1 is the IP of my CME.
identify the type of the IP phone:

ephone 1
  type CIPC


Result:
وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

الاثنين، 1 أبريل، 2013

HP Network Simulator: 8- OSPF


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 8- OSPF



وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

HP Network Simulator: 7- RIP


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 7- RIP



وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم

HP Network Simulator: 6- Static Routing


بسم الله والحمد لله والصلاة والسلام علي رسول الله وآله وصحبه وإخوانه وسلم

HP Network Simulator: 6- Static Routing



hardcfg:

R1
AddSerial -local 127.0.0.1 -lport 7001 -dest 127.0.0.1 -dport 7002

AddSerial -local 127.0.0.1 -lport 7003 -dest 127.0.0.1 -dport 7004

R2
AddSerial -local 127.0.0.1 -lport 7002 -dest 127.0.0.1 -dport 7001

AddSerial -local 127.0.0.1 -lport 7008 -dest 127.0.0.1 -dport 7007

AddSerial -local 127.0.0.1 -lport 7009 -dest 127.0.0.1 -dport 7010

R3
AddSerial -local 127.0.0.1 -lport 7004 -dest 127.0.0.1 -dport 7003

AddSerial -local 127.0.0.1 -lport 7007 -dest 127.0.0.1 -dport 7008

AddSerial -local 127.0.0.1 -lport 7011 -dest 127.0.0.1 -dport 7012

R4
AddSerial -local 127.0.0.1 -lport 7010 -dest 127.0.0.1 -dport 7009

وصلي الله وسلم وبارك علي النبي وآله وصحبه وإخوانه وسلم
